Maintenance of Truck Scale Grounding Device
August 17,2022
After the truck scale installation and commissioning process, many customers neglect the maintenance of the grounding device. The grounding device not only copes with lightning strikes but also plays an anti-interference and protection role. Therefore, the grounding device does not need to be maintained after installation. In the future operation of the grounding device, the grounding wire and the grounding body will be damaged or broken due to external force damage or corrosion, and the grounding resistance will also change with the change in the soil. Units are regularly inspected and maintained.
Inspection of Grounding Device of Truck Scale
- The inspection cycle in the operation of the grounding device
①The load bearing of the truck scale is checked once a year, usually before the thunderstorm season.
②The grounding wire of the building of the weighing room is generally checked 1-2 times a year according to the operating conditions.
③ The grounding device of the truck scale instrument and sensor lightning protection device shall be checked at least once a year before the thunderstorm season.
④If there is corrosive soil around the grounding device, the grounding body under the ground should be inspected every 3 to 5 years according to the operating conditions.
⑤ The grounding resistance of the grounding device is generally measured once every 1 to 3 years according to the local soil corrosion situation.
- Inspection items
①Check the contact performance of the grounding device of the 100-ton truck scale: Check whether the contact of each connection point is good and whether there is damage, breakage, or corrosion.
②Corrosion degree inspection of the grounding body in a corrosive environment: For soil areas containing heavy acid, alkali, salt, and other chemical components (generally chemical production enterprises, pharmaceutical production enterprises, and some food industry enterprises), the soil areas above 500mm below the ground should be inspected. The degree of corrosion of the grounding body.
③ Grounding resistance inspection: It should be measured when the soil resistivity is high (usually before the rainy season), and the measurement results should be analyzed and compared with the original design requirements.
④After overhauling the load bearing of the 100-ton truck scale, check whether the connection of the grounding wire is firm and reliable.
- Improvement measures when the grounding resistance value of the grounding device does not meet the requirements
Increase the total length of the grounding body or increase the number of vertical grounding bodies, replace the soil with low soil resistivity around the grounding body, such as yellow clay and black soil (soil resistivity is below 50Ωm), use chemical resistance reducing agents, and treat the grounding body, etc.
How to prolong the life of a truck scale?
To prolong the service life of the truck scale, it is recommended to check it regularly every six months. The scale of each vehicle shall be calibrated and tested by a service agency approved by the state, and its certified test weight shall not be less than 25000 pounds. Foundation maintenance is also very important. If not treated in time, small cracks will expand rapidly. Providing a suitable site, regular inspection and maintenance will help your truck scale stand the test of time.
